ESD Rubber Table Mat 1.8mm-3mm Thick Anti-Static Surface

Product Categories

Shanghai Herzesd Industrial Co., Ltd

Trust Seal

Verified Supplier

Credit Check

Supplier Assessment

Contact Now

ESD Rubber Table Mat 1.8mm-3mm Thick Anti-Static Surface

Name: ESD Rubber Table Mat 18mm3mm Thick AntiStatic Surface
Brand: Herzesd
Price: 58 USD

China ESD Rubber Table Mat 1.8mm-3mm Thick Anti-Static Surface wholesale

Place of Origin : Shanghai

Brand Name : Herzesd

Model Number : HZ-30617

MOQ : 100

Price : $58-72

Model : HZ-30617

Color : Green/Grey/Blue

Thickness : 1.8mm,2mm,3mm

Normal Size : 1m*10m;1.2m*10m

Material : Rubber

Volume Resistance : 10e7-10e10 ohm.cm

Surface Resistance : ≤10e6ohm

Surface Type : Matt/Glossy

Static Dissipation Resistance : 10e7-10e9 ohm

Friction Electrostatic Charge : <100V

Conductive Layer Resistance : ≤10e6 ohm

Conductive Friction Charge : <50V

High Temp Resistance : 300°C

Low Temp Resistance : -30°C to 70°C

Burning Point : 400°C

Contact Now

ESD Table Mat

ESD table mats are designed to drain static charges from items placed on its surface. They also protect the surface of the ESD sensitive devices from wear-and-tear. Made from durable materials, the ESD safe mats are designed to be long-lasting whilst maintaining their antistatic properties.

Model	HZ-30617
Thickness	1.8mm,2mm,3mm
Normal Size	1m10m;1.2m10m
Color	Green/Grey/Blue
Surface	Matt/Glossy
Volume resistance	10e7-10e10 ohm.cm

ESD Rubber Table Mat 1.8mm-3mm Thick Anti-Static Surface

Highly wear-resistant，good toughness, bending resistance, not easy to break

The static dissipative layer on the surface and the conductive layer on the bottom surface form a double-layer composite structure，Paste closely

Easier to close to table surface，Anti-aging and long use time

High temperature resistance, no discoloration at 300°C, no burning at 400°C, no decomposition at low temperature -30°C--70°C

Feature
Static dissipation layer	Surface resistance	10e7 -10e9 ohm
Static dissipation layer		Friction electrostatic charge	<100V
Conductive layer	Surface resistance	≤10 6 ohm
Conductive layer		Friction electrostatic charge	<50V
Volume Resistance	10 7 -10 10 ohm·cm

1, Why You Need ESD Protect For Your Production Line? Electronic Components Or Assemblies At Risk From Electrostatic Discharges (ESD) Are Among Those Sensitive Elements Which Can Be Destroyed Or Damaged If The Permitted Levels Of Current Or Impact Energy Are Exceeded. As A Rule, These Are Always Semi-Conducting Components And Most Are Also Thick- And Thin-Film Construction Elements. This Type Of Construction Element Is Mostly Damaged Through Human Mishandling. A Human-Being Can Charge Several Thousands Of Volts Just By Walking. A Discharge Can Be Felt By Humans From Approximately 2000-3000 V, A Current Which Is Already Well Above The 'Tolerance Level' Of Many ESD Components. Before Buying Or Implementing ESD Safe Products One Needs Implementing An ESD Safe Procedure According To The ESD Standards IEC 61340 Or ANSI S2020 Which Is The Foundation Of ESD Preventive Protective Work And A Greater Guarantee Of Quality Assurance. Besides Our Anti-Static Conductive ESD Workstations We Offer An Extensive Range Of Antistatic ESD Chairs, Antistatic ESD Cleaning & Maintenance, Antistatic ESD Clothing, ESD Shoes ESD Footwear, Antistatic ESD Flooring & Antistatic ESD Table Mats, ESD Safe Packaging, ESD Personal Grounding Materials, Anti-Static ESD Protective Storage & Warehousing Systems EPA, ESD Storage Boxes, ESD Test & Measuring Equipment, ESD Trainings, ESD Support & ESD Audits.

2. Why You Choose HerzESD?
HerzESD Strives To Serve Our Customers Better By Offering Correct And Clear Explanatory Answers.
We Try To Do So, Even When Informing Our Customers Better, Means Contradicting A More Established But Sometimes Flawed Opinions On
The Market.
At HerzESD We Pride Ourselves On Ensuring The Only Correct ESD Solution.
To Continue This Vision We Need Reliable ESD Manufacturers And Suppliers On Which We Can Always Count. HerzESD Is A Solid Partner
And Together With Our International Partners We Stay Strong And Vigilant In Regards To Possible Improvements Or New Solutions In
Tackling And Controlling Static Electricity.
